5000W 48v 300ah LiFePO4 Lithium Battery Stacked Household Energy Storage System

  • 1
  • 2

Brand Name : JHOTA

Model Number : HLSB03

Certification : CE

Place of Origin : Guangdong, China

MOQ : 1

Price : Negotiable

Payment Terms : T/T

Supply Ability : 100pcs

Delivery Time : 30-40 days

Packaging Details : Carton

AC Output Voltage Waveform : Pure Sine Wave

Battery Type : LiFePO4

Special Features : Remote Control

Power Source : Solar Panel

Contact Now

Specification
Model Number
HLSB03
Battery parameters
Nominal Voltage
48V
Rated Capacity
Typical 300Ah
Minimum 290Ah
Charging Voltage
54.75V
Charging Mode
C.C / C.V.
Voltage at end of Discharge
37.5V
Rated Charge Current
≤60A
Maximum Continuous Charge Current
≤80A
Internal Impedance
＜100mΩ
Rated Discharge Current
≤200A
Maximum Continuous Discharge Current
≤200A
Overcharge Voltage
3.65±0.05V (Adjustable)
Over Discharge Cut Off Voltage
2.5±0.01V (Adjustable)
Over Current
Discharge overcurrent value: ≧205A
Short Circuit
Detection condition
Release condition
Operation Temperature Range
Charge: 0~55℃
Discharge: -20~55℃
Storage Temperature Range
Less than 7 day : -20~65℃

Product Description
Stacked Home Energy Storage System 5000W inverter 300AH Battery 48V


5000W 48v 300ah LiFePO4 Lithium Battery Stacked Household Energy Storage System

Quick Details:

1. Warrenty: 3 Years
2. OEM/ODM: Accepatable
3. AC Rated Output Power: 5KW
4. Inverter Type: Pure Sine Wave
5. Power Source: Solar Panel, Power Battery, Municipal electricity
6. Controller Type: MPPT

5000W 48v 300ah LiFePO4 Lithium Battery Stacked Household Energy Storage System

Inverter parameters
Solar Input
Maximum PV Open-circuit Voltage
500vdc
PV Working Voltage Range
120-500Vdc
MPPT Voltage Range
120-450Vdc
Maximum PV Input Current
18A
Maximum PV Input Power
5200W
Maximum PV Charging Current
80A
AC Input (generator / grid)
Mains Maximum Charging Current
40A
Rated Input Voltage
110/120Vac
Input Voltage Range
(90Vac~140Vac)±2%
Frequency
50Hz/ 60Hz (Automatic Detection)
Mains Charging Efficiency
>95%
Switch Time (bypass and inverter)
10ms(Typical Value)
Maximum Bypass Overload Current
63A
AC Output
Output Voltage Waveform
Pure Sine Wave
Rated Output Voltage
120 (100/105/110Vac)
Rated Output Power
5000 (4100/4300/4500VA)
Rated Output Power
5000 (4100/4300/4500W)
Peak Power
10000VA
On-load Motor Capacity
4HP
Output Frequency Range (Hz)
50Hz土0.3Hz/60Hz±0.3Hz
Maximum Efficiency
>90%
No-load Loss
Non Energy-saving Mode: ≤50W Energy-saving Mode:≤25W (Manual Setup)
General
Humidity Range
5% to 95%(Conformal Coating Protection)
Dimensions
603*430*1350mm
Weight
about 210kg
Communication mode
Working voltage, working current, remaining capacity
Our Factory
1. Our product range: solar panels, inverters, controllers, batteries, on-grid and off-grid solar systems. Our goal is to manufacture and deliver reliable and innovative solar panels and solar energy solutions to the world. As a production manufacturer, we are constantly updating our technology to use clean, renewable solar energy more efficiently and encourage our customers to explore responsibly to offset our carbon footprint.
2. Our commitment to quality and service is unmatched in the industry. In a rapidly innovating industry, it's best to have a trusted partner like JHOTA to help you navigate your options so you can get the most out of your renewable energy investment.
3. JHOTA Home Energy Storage System battery is a Ground mounted lithium battery pack which consists of long life-span LiFePO4 battery cells and functional BMS. It can store and release electric energy based on the requirements of the inverter controller. It is mainly for home energy storage system.

5000W 48v 300ah LiFePO4 Lithium Battery Stacked Household Energy Storage System

FAQ:

1.What’s the lead time for mass production?
It depends on the actual situation. 48V100ah LFP battery pack,3-7 days with stock, if without stock, that will be depends on your order quantity, normally needs 20-25 days.


2. Do you accept ODM/OEM orders?
Yes, we can accept OEM/ODM, you can change the logo and function as you want.


3.How can I be your distributor or service partner?
Yes, please directly email to us, we can discuss about this. We need to know your target market, what application you want to cover, and estimated annual purchase volume.


4. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment.
